Stationary Quick Reponse Wall Mounted C2H4 Ethylene Gas Leak
Detector For Ripening Monitoring
There is low and high alarm point settings for YT-95H-B-C2H4
ethylene gas leak detector. When the ethylene gas concentration
reach the target alarm point,there will have light and voice alarm
to remind people.
Quick details
1.Adopt 2.4-inch high-definition color screen, 120 degree angle of
view
2.Built-in micro-sampling pump, pump flow is stable at 800mL/min
3.Large capacity and fast storage, storage space can be customized
4.Infrared remote control function and button function
5.4-20mA current signal, RS485 digital signal, 1 set of relay
signal output
6.Support multiple gas display units to switch freely, the
concentration value is automatically converted by the system
Specification
| Size | (H x W x D)320*230*110mm |
| Weight | 3000g |
| Detected principle | Electrochemistry/PID |
| Measure range | 0-10ppm,0-20ppm,50ppm,100ppm,0-500ppm,1000ppm |
| Resolution | 0.001ppm,0.01PPM,0.1ppm,1PPM |
| Precision | ≤±2%F.S (Higher measure range can be customized) |
| Pump flow rate | Flow rate range:0-800 mL/Min |
| Display Screen | 2.4-inch color display, resolution 320*240 resolution |
| Display contents | Gas molecular formula, concentration, unit, pump status, etc. |
| Alarm | buzzer, alarm status prompt on the display |
| Data logging | Independent SD memory card, automatic measurement of measurement
data, customizable recording interval |
| Communication and data download | It can be directly connected to the computer via USB to quickly
download the TXT file for storing data; with the PC software to
download, store, analyze and print the data. |
| Power supply | 12-36V DC |
| Wireless network | Built-in module to upload data to the network platform, regardless
of distance (optional) |
| Network frequency | 2.4G high frequency |
| Installation method | Wall-mounted, pipe-flow type (optional) |
| Language | Chinese / English |
| Humidity | 0～95%RH (no condensation) (optional filtration device can be
equipped if in hyperhumidic ares ) |
| Temperature | -20℃~+50℃ (optional filter can be equipped if over temperature) |
| Explosion-proof | Ex d IIC T6 Gb |
| Protection degree | IP65 |
| Certificate | measuring instrument license, explosion-proof certificate,
CE,ISO9001 |
Optional function
7.Pretreatment system to achieve harsh environment detection such
as high temperature, high humidity and high dust (optional)
8.Built-in module to upload data to EPA platform or other public
platform, transmitting signals without distance limitation
(optional)
9.Can be equipped with 1 set of relay signals (optional)
10.GPRS wireless transmission function, SMS reminder service
(optional)
FAQ
1. Can I have a sample order?
Yes, we welcome sample order to test and check quality.
2. What is the lead time?
Usually, we will ship in 3 days, for big quantity orders, the
delivery time is negotiable.
3. Do you have any MOQ limit?
We don’t have a MOQ limit, 1 pc are also welcome.
4. Do you offer guarantee for the gas detectors?
Yes, we offer one year guarantee for all the detectors. we also
provide life-long paid service. As an experienced manufacturer, you
can rest assured of the quality and after-sales service.
5. What about after-sale service?
We provide guarantee of 12months, free charge of repair under
correct operation. We will response to your inquiry 24h x 7 days,
and provide you technical support through email and phone calls in
time.
6. What is the payment terms?
Visa, Mastercard, e-Checking, T/T, Western Union, Alipay.
7. How do you send the detectors?
DHL, FedEX, UPS, TNT, by air, by sea.
8. What certificates do you have?
CE, ISO, CNEX explosion proof, CMC.
If you have any other requriements with certifications, we also
would like to help you
9. How about the packing?
Aluminum suitcase, carton box
10. How do you control your quality?
First, we will do aging test on all the raw material and PCB, and
during production we will calibrate all the detectors well, last
but the most important, we have professional QC team to inspect the
detectors pc by one pc before shipment.
