    Fixed Exhaust Gas Detector SO2 Sulfur Dioxide Alarm With CE EX Certificate

    Ask Lasest Price
    Brand Name : YuanTe
    Model Number : YT-95H-SO2-A
    Certification : CE CNEX ISO9001-2015
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 500PCS/DAY
    Delivery Time : 2-3 days
    • Product Details
    • Company Profile

    Fixed Exhaust Gas Detector SO2 Sulfur Dioxide Alarm With CE EX Certificate


    Fixed Exhaust Gas Detector SO2 Sulfur dioxide Alarm with CE EX certificate

    Application areas of SO2: weather forecast / air quality, food factories, pharmaceutical companies, environmental companies, research institutions, mining, etc. This SO2 gas detector is high precision, new detection technique, strong stability to be used in all kinds of environments.

    Technical Parameters

    Gas detected

    Sulfur dioxide, SO2

    Detection principle

    Electrochemistry

    Install method

    Wall-mounted, piping type, flow-type (according to the detected environment)

    Measure range

    0-10ppm, 0-25ppm, 0-100ppm,0-250ppm, 0-500ppm,0-1000ppm,0-2000ppm, 0-5000ppm

    Resolution

    0.001ppm, 0.01ppm, 0.1ppm, 1ppm

    Precision

    ≤± 1-2% FS

    Signal output

    4-20mA, 0-5V, RS485, relay(optional)

    Response time

    ≤10S

    Recovery time

    ≤10S

    Repeatability

    ≤±1%

    Linearity error

    ≤±1%

    Zero shift

    ≤±1%(FS/year)

    Display

    High-light nixie tube display

    Connection mode

    G1/2 external thread explosion-proof flexible pipe

    Unit

    ppm

    Temperature

    -20 to 50°C

    Humidity

    0-95%RH

    Explosion-proof

    Ex dⅡCT6

    Degree of protection

    IP65

    Alarm

    Sound, light

    Operating time

    24H

    Dimensions

    180*150*90mm

    Weight

    ≤2kg



    Main Features:
    1. Monitor the Sulfur dioxide, SO2 gas in environment or pipeline.
    2. With self-calibration and zero calibration function, makes the detection more accurate and reliable.
    3. With temperature compensation, this is able to realize gas concentration compensation under conditions of different temperatures.

    4. With display and alarm, alarm mode is sound and light, alarm point is settable.
    4. Infrared ray controller can remote control alarm point settings, zero calibration, and address modification. (optional)
    5. Can output one or two on-off signals, can drive ventilator or solenoid valve and other external devices. (optional)
    6. Working Voltage:24V DC
    7. Standard equipped with three-wire system 4-20mA analog output; relay output; RS485 output.
    8. Unique infrared ray control function, which can non-contacted control the device.
    9. Being compatible with all kinds of controlled alarms, PLC, DCS and other control system, can be remote monitored.
    10. Explosion-proof design, fast, reliable and stable.
    11. Explosion-proof grade: Ex dⅡCT6
    12. With self-calibration function, and three standard keys will be used to realize on-site maintenance.
    13. Detachable probe/gas cell: It is very easy to calibrate and replace sensor.




    FAQ:

    Q1.What's the minimum order?
    A: I piece is welcomed.

    Q2. What about the lead time?
    A: We usually deliver the goods in 2-5 working days after the order confirmed.


    Q3. How do you ship the goods and how long does it take to arrive?
    A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 2-5 days to arrive. Airline and sea shipping also optional.


    Q4. Is it OK to print my logo on the gas detector?
    A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.


    Q5: Do you offer guarantee for the products?
    A: Yes, we offer 1 year warranty to our products.
