Sky2000 series products are a rapid response, accurate detection of
gas detector. Built-in sampling pump, fast sampling speed, large
flow. Unique design, small size, easy to carry, the shell is made
of high strength special engineering plastic, can meet the needs of
various environments and occasions. We are committed to providing
users with the most reliable, accurate and safe gas detector
solutions.
Characteristic & Function
1. LCD lattice display, gas type, unit, concentration, and local
time can be displayed on the screen.
2. Support operation in Chinese and English, easy to switch.
3. The unit of gas concentration PPM and mg/m3 can be changed
quickly.
4. Explosion-proof certification, explosion-proof grade :II 2G Ex
ia IIC T4 Ga IP66.
5. Monitor the hydrogen concentration in the environment and
confined space and give an alarm.
6. With self-calibration and zero calibration function, so that the
detection is more accurate and reliable.
7. Press once to restore factory Settings, avoid the trouble of
misoperation.
8. With the function of temperature and pressure compensation, can
realize the gas concentration compensation under different
temperature or pressure conditions.
9. Sound and light alarm, alarm point can be set.
10. Large capacity rechargeable lithium polymer batteries.
Specificiation
Gas Detected | HCL HCN |
Detection principle | Electrochemistry |
Sampling Method | Pumping suction, flow rate can up to 1L/min, ten grades of pumping
suction for selection. |
Measure Range | Customized |
Resolution | Customized |
Precision | 2%FS |
Signal Output | High-speed data transmission by USB, available for data downloading
and
printing (Optional function) |
Response Time | ≤10S | Recovery Time | ≤10S |
Repeatability | ≤±1% | Linearity error | ≤±1% |
Zero shift | ≤±1%(F.S/year) | Display | LCD dot matrix display |
Operating language | Chinese/English | Gas unit | ppm, mg/m3 |
Temperature | -20ºC~50ºC | Humidity | 0-95%RH |
Explosion-Proof | Exiia IICT4 | Degree of protection | IP66 |
Alarm mode | Sound, light, vibration | Operating time | 12h |
Dimensions | 205*75*32mm | Weight | 300g |
