Flammable Gas CH4 H2 Gas Detector IP67 with Explosion-Proof Iecex
Certificate Data logger
A Professional: We have been focused on gas detection devices for more than 10
years and been cooperating with PB group, PetroChina, Sinopec, Huawei, Samsung, Panasonic, etc famous companies. We are with rich
experience to provide you professional solutions.
B Innovation: Strong R&D team (invest 40% revenues into research and
experienced engineers team) makes our products stand out in the
market.
C Quality: International top brands sensor and IC /100% production test, make
sure a good quality.
D Professional technical support: Provide detailed pre-sales and after-sales technical support, no
need to worry about any problem during usage.
E Completed certifications: ATEX / IECEX / SIL / CE / CNEX / ISO9001/, meet government standard
as well guarantee your safety health.
F Services: We provide 24*7 hours service, if there have any question, Celia
will reply you in 1 hours. Meanwhile, we can provide OEM services.
G Delivery: We can ship it out in 2-3 days. For some mass production and
special customised gas analyzer, we can ship it out in 7 days.
Functions:
1. Simultaneous upto 5 gases can be monitored, multiple numerical
display including real-time data, TWA, STEL, MAX, MIN multiple
numerical.
2. The screen can be automatically turned 180 degrees, which is
convenient for viewing in special operating environments
3. Pump suction and diffusion dual use, to provide operators with
more reliable protection
4. With a water trap filter, it can effectively filter water, oil,
dust and other impurities. It can also be used in harsh industrial
environments such as coal mines and petroleum fields.
5. Optional Bluetooth function, data can be transmitted to the
mobile phone or PC in real time
6. Storage function, one-click data export, convenient for users to
analyze
7. Automatic prompts for voltage and pump failure alarms makes it more
user friendly.
8. PPM and mg/m³ gas unit switch, the concentration value is
automatically converted by the system.
Specifications
| Gas Detected | H2S, CO, NH3,LEL, O2, VOC etc |
| Detection principle | Electrochemical, catalytic combustion, PID |
| Sampling Method | Pumping suction |
| Measure Range | H2S 0-100PPM, CO 0-1000PPM, NH3 0-100PPM, LEL 0-100%LEL, O2
0-30%VOL, VOC 0-100PPM |
| Resolution | H2S 0.1PPM, CO 1PPM, NH3 0-100PPM , LEL 1%LEL, O2 0.01%VOL, VOC
0.1PPM |
| Precision | ≤±2%F.S except for special gases |
| Response Time | ≤30 seconds | Recovery Time | ≤10S |
| Repeatability | ≤±1% | Linearity error | ≤±1% |
| Zero shift | ≤±1%F.S/year | Display | LCD dot matrix display |
| Operating language | Chinese/English | Gas unit | Units are switchable |
| Temperature | -20℃-50℃ | Humidity | 0-90%RH |
| Explosion-Proof | IECEx: Ex ia IIC T4 Ga ATEX: II 1G Ex ia IIC T4 Ga | Degree of protection | IP67 |
| Alarm mode | Sound, light, vibration | Environmental pressure | 86～106Kpa |
| Dimensions | 157*84.5*59.5mm | Weight | 365g |
Product advantage
- Support for multilingual switching.
- With data recording function, it can export data with one click,
making it easy for users to analyze.
- The screen can automatically rotate 180 degrees for easy viewing.
- It can monitor up to 5 types of gases, display real-time data, and
display multiple values such as TWA, STEL, MAX, and MIN.
- Optional Bluetooth function for real-time data transmission to
mobile phones or PCs
- Multiple security protection includes the function of alarm under
people, password protection, security reminder, alarm and high-low
alarm locking.
- Built in sampling pump for faster response. It can be connected to
a sampling hose for convenient remote or enclosed space detection.
- The protection level is IP67 and can pass the three meter drop test
and EMC anti-static interference test. It is also IECEx, ATEX
certified, and has an explosion-proof rating of Exia IICT4 Ga.
Application:
Furniture, Floor, Wallpaper, Coating, Gardening, Interior
Decoration and Renovation, Dyestuff, Papermaking, Pharmacy, Health
Care, Foodstuff, Antiseptic.
Disinfection, Chemical Fertilizer, Resin, Adhesive, Pesticide, Raw
Material, Sample, Technological Process,
Livestock Farm, Refuse Processing Plant, Perm Place.
Bio-pharmaceutical Plant, Green Household, Livestock Breeding,
Green House Cultivating, Warehouse Logistics, Brewing And
Fermentation, Agricultural Production.
