Methane Gas Detector PPM LEL VOL Automatic Switch Detection CH4
Meter Monitor Analyzer Waterproof Explosion-proof
Methane Gas Detector PPM LEL VOL Advantage:
Powerful function, more user-friendly operation
1. Optional Bluetooth function, data can be transmitted to the mobile
phone or PC in real tim Standard storage function, one-click data
export, convenient for users to analyze
2. Unique modifiable ID identification function, convenient for
users to allocate and manage the instrument
3. A full range of automatic detection functions, automatic prompts
for voltage, pump failure alarms, etc., more comfortable to use
4. Support PPM and mg/m3 gas unit switch, the concentration value
is automatically converted by the system Support each channel
sensor to restore the factory setting separately
5. Support multi-language including English.Chinese and etc.
6. The screen can be automatically turned 180 degrees, which is
convenient for viewing in specia operating environments
7. Built-in powerful sampling pump, fast detection speed
8. Can be connected 20m sampling tube externally, which is
convenient for long-distance or confined space detection
9. With a water trap filter, it can effectively filter water, oil,
dust and other impurities. It can also be used in harsh industrial
environments such as coal mines and petroleum fields
10. The protection level of the instrument reaches IP67
11. The man down alarm function has upgraded the safety of
underground operators
12. Password protection function prevents non-operators from
modifying menu parameters
13. With safety reminder function, sound and light vibration alarm
function, let operators work without worries
14. The high and low alarm latched function allows the operator to
better capture the sudden change of the gas concentratio value
15. The instrument can detect 1-5 gases at the same time
16. Real-time value, TWA, STEL, MAX, MIN multiple numerical display
Accessories & Configuration List
Standard Accessories
SKY3000
Aluminum suitcase
A charging adapter
User Manual
Qualification/Calibration certificate
Filter
Storage function(USB cable)
Optional Accessories
Probe
Tube
Bluetooth App
Aplication for Methane Gas Detector PPM LEL VOL
Mainly used in industrials, chemical plant, Natural Gas Company, granary, laboratory, petroleum chemical industry,metallurgy, mining, fire, gas, environmental protection, electric
power, communication, papermaking, printing and dyeing, food
reserves, city water supply, sewage treatment, food, brewing, research, education, national defense and other
places.
Methane Gas Detector PPM LEL VOL Specification:
| Sampling method | Pump suction |
| Gas type | CH4 Methane etc, other gases are customized |
| Measure range | 0-5000ppm, 0-100%LEL, 0-100%VOL, other measure ranges are customized |
| Resolution | 1ppm, 1%LEL, 1%VOL, etc other resolutions are customized. |
| Response time | ≤10 seconds |
| Precsiion | ≤±1%F.S |
| Language | English(Other languages can be customized) |
| Automatically test and calibrate after power-on | Including reset, maximum value (MAX), minimum value (MIN), STEL,
TWA value |
| Unit | PPM and mg/m³ can be switched |
| Disaply | monochrome graphics (160 x96) ,screen can be automatically flipped |
| Backlight | The backlight time can be manually set, and will be turned on
automatically when an alarm is issued |
| Data record | Can store 100,000 sets data, the storage interval is adjustable
from 5 to 3600 seconds, data can be exported |
| Alarm | 95dB buzzer (@30cm), vibration alarm and flashing red LED and alarm
status indication on the screen, alarm latched; diagnostic alarm
and battery undervoltage alarm, pump block alarm; man down alarm,
with early warning and optional real-time remote Bluetooth
notification function |
| Battery | 3.7V rechargeable lithium battery, battery capacity 2200mA |
| Working hours | More than 15 hours in continuous pumping mode |
| Charger | Travel charger with DC interface, charging time ≥ 4 hours |
| Explosion-proof grade | IECEX/ATEX(II IG Ex ia IIC T4
CNEX:Ex ia IIC T4 Ga |
Certification
(EU regulations) | 2004/108/EC(EMC)
1995/5/EC(Radio)
94/9/EC(ATEX) |
| Protection grade | IP67/IP68 |
| Working temperature | -20ºC~+50ºC |
| Humidity | 0~90%RH(no condensation) |
| Environmental pressure | 86~106Kpa |
| Size | 157*84.5*59.5mm (including back clip/water trap filter) (length *
width * height) |
| Weight | 365g (including battery, belt clip and filter) |
| Bluetooth function(Optional) | PID Benzene C6H6 Gas Concentration Level Detector data can be
transmitted to the mobile phone or PC in real time |
Factory Information
Our company Shenzhen Yuante Co., Ltd is specializing in the
production, research and development of gas detector for more than 10 years. We have ATEX, IECEx, CE and ISO certificate. Main product have SKY2000, SKY3000, SKY6000, SKY8000,
YT-95H and YT-1200H. We have portable one and fixed one. Welcome to
consult.
Q: What is your terms of payment ?
A:We accept VISA, MasterCard and TT.
Q: When do you reply to messages?
A: We are on line 24*7.
Q: What is the warranty for your product ?
A: 12 months or 24 months, Lifetime maintenance for Methane Gas Detector PPM LEL VOL.
Q: When do you send the products? And how do you send it ?
A: For the small order, we will send out the goods with 1-2 days,
If have stock ,we will send immediately.
We send Methane Gas Detector PPM LEL VOL by ups, fedex, tnt or dhl.
For big order, such as: 100pcs, 200pcs, Methane Gas Detector PPM LEL VOL will be ready in 15 days.
Q:Do you accept OEM or revised logo, color, model, size?
A:Yes, we accept OEM.
We can make Methane Gas Detector PPM LEL VOL according to customer personal requirement.
Q: How about the quality of the managements ?
A: We have a complete quality control system , Methane Gas Detector PPM LEL VOL will be fully pre-inspection by QC departments before shipping to
you . We have the certification of ISO,CE, ATEX. And we can send
the certification test of our company to you.
Q: How about your after-sale service?
A: After sending, we will track Methane Gas Detector PPM LEL VOL for you , until you get Methane Gas Detector PPM LEL VOL.
When you got Methane Gas Detector PPM LEL VOL, test Methane Gas Detector PPM LEL VOL, and give me a feedback.
If you have any questions about the problem, contact with us, we
will offer the solve way for you.
Why should you buy from us not from other suppliers?
A Professional: We have been focused on gas detection devices for more than 10
years and been cooperating with PB group, PetroChina, Sinopec, Huawei, Samsung, Panasonic, etc famous companies. We are with rich
experience to provide you professional solutions.
B Innovation: Strong R&D team (invest 40% revenues into research and
experienced engineers team) makes our products stand out in the
market.
C Quality: International top brands sensor and IC /100% production test, make
sure a good quality.
D Professional technical support: Provide detailed pre-sales and after-sales technical support, no
need to worry about any problem during usage.
E Completed certifications: ATEX / IECEX / SIL / CE / CNEX / ISO9001/, meet government standard
as well guarantee your safety health.
F Services: We provide 24*7 hours service, if there have any question, Celia
will reply you in 1 hours. Meanwhile, we can provide OEM services.
G Delivery: We can ship it out in 2-3 days. For some mass production and
special customised gas analyzer, we can ship it out in 7 days.
